Electronic box for Danfoss BD35F and BD50F compressors

Name: Electronic box for Danfoss BD35F and BD50F compressors
Brand: Indel Webasto

The Secop 101N0212 electronic box for Danfoss BD35F and BD50F compressors lets you power the Indel Webasto refrigeration systems on your boat.

INDEL - WEBASTO - Secop 101N0212 control box for Danfoss BD35F and BD50F compressors

The Secop 101N0212 electronic control unit plays a crucial role in the control, protection and efficient operation of Danfoss BD35F and BD50F compressors in a variety of refrigeration and air-conditioning applications, offering advanced control features and fault protection.

It replaces the old Secop 101N0210 box.
It can also be used in air-conditioning systems or similar applications on your boat, as long as it is used with either a Danfoss BD35F or BD50F compressor .

ESSENTIAL FOR REFRIGERATION

The Secop 101N0212 electronic control unit is an integral part of the control and protection system for Danfoss BD35F and BD50F compressors:

Compressor speed control : adjusts compressor speed to optimize cooling performance as needed
Thermostat control : manages the thermostat, which can be either an on/off switch or an electronic thermostat with NTC temperature sensor
Eco function : features an eco function to optimize compressor speed to minimize energy consumption
Battery protection : includes battery protection to prevent excessive discharge when used on limited power sources such as boat batteries

This box is therefore essential for the proper operation and energy efficiency of on-board refrigeration systems. It ensures that the compressor operates at optimum levels, while protecting the system against voltage variations and reducing energy consumption .

CONNECTION SPECIFICATIONS SECOP 101N0212 ELECTRONIC BOX

-/+	Battery connection. Nominal voltage 12/24V DC, range 9 to 32V DC
+/F	Fan connection (max 5W), always connect a 12V fan (even in 24V systems)
D/I	Connection of an error LED between + and D/I for simple error indication. Constant current 10 mA
C/P	Connection of a battery protection resistor to select the battery cut-off value
C+T	Connection of a mechanical or mechanical thermostat in series with speed programming resistor or an NTC temperature sensor
