Electromagnetic Bilge Pump Switch

AUTOMATIC WATER LEVEL DETECTION

The switch detects the water level in the bilge using its electric field sensor. The pump turns on when the water reaches 41 mm and turns off as soon as the level drops below 9.5 mm.

The system operates without a float or moving parts. The sensors do not come into direct contact with the water, which minimizes the risk of corrosion and wear associated with mechanical operation.

• Pump starts at 41 mm of water
• Automatic shutdown below 9.5 mm
• Detection without a float or moving parts
• Electronics fully protected in a waterproof housing

A 3-second delay prevents the pump from starting unnecessarily when water moves in the bilge, particularly due to waves or the boat’s movement.

KEY FEATURES:

• 12/24 V power supply
• Automatic shut-off at 9.5 mm of water
• Pump activates at 41 mm of water
• Electric-field detection with no moving parts
• 3-second delay to prevent accidental starts

BOX CONTENTS:

• 1 - Electric-field bilge pump switch with cable (1 m)
• 1 - PDF documentation
