LiFePO4 Lithium Case 36V

LifeP04 36V 50A lithium battery

The high-performance LifeP04 36V 50A lithium case SH LITHIUM features the following characteristics:

• Output voltage: 43.8 V
• Capacity: 50A
• Weight: 16 kg
• Dimensions (L x W x H) : 39.1 x 30.7 x 17.3 cm
• Continuous discharge current: 100A
• Shock-resistant-crushproof
• Automatic pressure relief valve
• LifeP04 chemistry
• 12S mounting
• Waterproof
• Assembled in France
• CE certified
• Charging temperature : 0 to 45 °C
• Discharge temperature: -25 to +65 °C

Integrated BMS and display

The Lifep04 36V 50A lithium case SH LITHIUM features a digital display that lets you see the battery's state of charge and voltage.

LiFePO4, or lithium iron phosphate, is a type of lithium battery-ion recognized for its safety, durability and stability. Unlike other types of lithium battery, it is less prone to overheating or fire hazards, making it a safe choice for marine applications.

It also incorporates a BMS that monitors and safely manages the battery by controlling voltage, balancing cell charge, protecting against overloads and overcurrents, and regulating temperature.

The BMS is programmed to allow 100% discharge, far exceeding the discharge capabilities of AGM and Gel batteries.

Finally, the case is equipped with an automatic pressure relief valve that regulates internal pressure in the event of atmospheric pressure variations. This prevents the case from deforming or bursting due to the pressure difference between inside and outside.

MAIN POINTS :

• LifeP04 lithium battery
• Rugged, waterproof carrying case
• For conventional and brushless electric motors

BOX CONTENTS :

• 1 - LifeP04 lithium case SH LITHIUM 36V 50A
• 1 - 36V battery charger
• 1 - PDF documentation
