Interface CZone Contact 6
Ref.
80-911-0140-00
CZone Contact 6 is a NMEA2000 digital switching module with 6 dry-contact relays. Controllable via an interface CZone or a compatible multifunction display, it manages positive or negative switching, reversible motors, modes and timers.
What's more, they feature a wide range of protections, including resettable PTC fuses-, electronic bypass and diagnostic LEDs.
80-911-0140-00
Interface CZone Contact 6
The Contact 6 CZone is an entry-level digital switchbox. It offers 6 independent channels, with positively or negatively controlled outputs. It's perfect for the electrical system of a pleasure boat or recreational vehicle, as well as a sub-whole of a large installation.
It can be networked via NMEA 2000 and controlled from a CZone Touch display, a networked multifunction display or a digital pressure or rocker switch, or wirelessly via a "Wireless Interface CZone".
The CZone Contact features 6 7.5A outputs, enabling installers to place modules closer to groups of consumers, thus lightening harnesses and reducing wiring costs.
Features :
- Entry-level 12V digital switch module for marine and recreational vehicle applications
- Stand-alone installation or networked with other equipment CZone
- Compatible with CZone multifunction displays
- 6 independent dry-contact relays for positive or negative control
- Uses proven CZone technology
- Built-in automatic fuses
- Cut-off relay-electronic circuit
- LED status/error indicators for all channels
- IPX5 protection rating
- NMEA2000
Technical data :
- Waterproof IPX5
- 100 x 156 x 42 mm
- Power consumption: 30mA (all channels off)/ 120mA (all channels on)
