2-channel 869 MHz radio control receiver

Quick - RRC R12+ radio-controlled receiver - 15A - 869MHz - 2 channels

Model: FRRRCR02P000A00

2-channel receivers

Dimensions: 143x142x62 mm

Weight: 370 g

Details :

• Full power range (from 10.5 to 31Vdc).
• Microcontroller-controlled functions.
• FSK modulation (869.8 Mhz).
• Operating temperatures from -15°C to +70°C.
• Indication of system operating status, errors and problems via LED and seven-segment display.
• Reverse polarity protection.
• Low battery protection.
• Memory capacity for 50 transmitters.
• Translation mode to activate several receivers, installed in different locations, using a single transmitter.
• Programmable digital filter.
• Can be connected to an external antenna.
