Auto Glide switch kit for automated flap management Lenco

AUTOGLIDE: GYROSCOPE AND ACCELEROMETER

The heart of the Auto Glide system is the control box. Equipped with a 3-axis gyro sensor and accelerometer, this box also receives the boat's engine and GPS data.

Every change in boat speed, heading, pitch and roll is taken into account.

All this information enables the Auto Glide system to make its own decisions to correct trim by raising or lowering the flaps automatically, whatever the speed.

LENCO AUTOGLIDE SWITCH

The AutoGlide switch is used to program the AutoGlide system, but also serves as a manual switch. It replaces a conventional flap switch.

With this switch you can switch the system to automatic mode (trim is automatically corrected according to angle, speed, etc.). You can also program 2 favorites to set your flaps in 2 positions to be activated at the touch of a button.

• 1 - AUTO : activates automatic mode.
• 2 - DN BÂBORD : manually lowers the port side of the bow.
• 3 - LED : pitch indicator.
• 4 - UP BOARD : manually raises the port side of the bow.
• 5 - FAV 1 : activates the boat's favorite stored position #1.
• 6 - HOLD : temporarily locks current boat position.
• 7 - DN TRIBORD : manually lowers the starboard side of the bow.
• 8 - LED : roll indicator.
• 9 - UP TRIBORD : manually raises the starboard side of the bow.
• 10 - FAV 2 : activates the boat's favorite saved position n°2.

MAIN POINTS :

• Waterproof
• NMEA2000 compatible
• Switch with LED
• Gyroscope, accelerometer
• Automatic flap management
• For single-acting electric flaps Lenco

BOX CONTENTS :

• 1 - Autoglide switch
• 1 - Autoglide control box
• 1 - Control box to flaps cable
• 1 - CAN 1 to NMEA2000 adapter cable
