Water unit with 4L storage tank - 24V - 22 L/min

Name: Water unit with 4L storage tank - 24V - 22 L/min
Brand: Flojet

Ref. FG014

The Flojet water unit consists of a Quad II 24V pump with a flow rate of 22 liters per minute and a pre-assembled 4-liter expansion tank . This constant-flow system has been designed for yachts with multiple taps and appliances (washing machine, dishwasher, ice maker, etc.).

Flojet - Water unit with 4L storage tank - 24V - 22 L/min

Technical data :

24V
5A fuse
On 1.9 bar - Off 2.8 bar.
Self-priming up to 3m.
Connections:
- Suction: 3/4" corrugated for 19mm hose.
- Discharge: 1/2'' corrugated for 13mm hose.
Dimensions: 191x286x325mm
Weight: 4kg.
