Xtream 4G router / WIFI / NMEA2000 / Bluetooth / Dual SIM all in one

4G XTREAM, WIFI ON THE HIGH SEAS

The 4G router comes with 2 external LTE antennas . The 4GXtream delivers an on-board Internet connection of up to 300 Mb/s (depending on the network).

It features independent dual-band Wi-Fi (2.4 and 5 GHz) for connecting up to 150 mobile devices .

Thanks to its integrated NMEA 2000 interface , it also broadcasts NMEA 2000 data so that popular applications and software can use the boat's navigation and instrumentation data.

ALL-IN-ONE 4G ROUTER

The 4G XTREAM features an integrated dual-band Wi-Fi router (2.4 & 5 Ghz), two SIM card readers , integrated GPS (for IOT and tracking applications) and an NMEA 2000 interface for broadcasting navigation data over the Wi-Fi network. There's also a Bluetooth interface for future applications.

The 2 external antennas connect to the coaxial ports on the front of the router via standard cables using the specialized LMR200 coaxial model. They should be located more than 50cm apart, and mounted at maximum cable length (7m) if possible.

Nb: 10m and 20m LMR400 coaxial cables are available as options for minimum losses

It is possible to connect to a wifi hotspot on the coast to create the on-board internal Wi-Fi network, but this is not recommended . Plan to use a WL510 Wi-Fi booster antenna (sold separately) connected to the WAN port to access a Wi-Fi hotspot (range up to 10 km)

MAIN FEATURES :

• Dual MIMO antennas
• 2 SIM card slots
• NMEA2000, GPS, Bluetooth
• Dual band (2.4 & 5 GHz)

CONTENTS OF BOX :

• 1 - 4GXTREAM modem
• 1 - Integrated NMEA2000 cable
• 1 - 12V power cable
• 2 - External LTE stick antennas
• 2 - Stainless steel platpont antenna supports
• 2 - LMR200 7m antenna cable
