AIS B650 Transponder

AIS Class B+ 5W SOTDMA Transponder

With SOTDMA, the B650 reserves its AIS transmission slots in advance. Messages are sent more consistently, especially when many vessels are transmitting at the same time. Its 5 W power output also gives it a greater range than AIS Class B 2 W transponders.

• Transmission AIS 5 W Class B+ SOTDMA
• -Receive Sensitivity: 111 dBm
• GNSS receiver with 72 satellite channels
• More reliable transmission in areas with heavy traffic

This AIS transponder is suitable for recreational boating, coastal cruising, offshore navigation, and areas with heavy maritime traffic.

Connection to onboard electronics

The B650 features NMEA 2000, NMEA 0183, and USB-C connections. Its NMEA 0183 multiplexing function allows data to be redistributed to NMEA 0183, USB, and Wi---Fi outputs, depending on the version.

• 12 V or 24 V DC power supply
• Average current draw: 120 mA at 12 V
• Peak current: 1.7 A at 12 V
• Weight: 400 grams

Its compact design makes installation easy. Status LEDs allow for quick monitoring of operation, while the IP68-rated housing protects the device on board.

KEY FEATURES:

• Status LED
• IP68 housing
• AIS Class B+ 5 W
• -Sensitivity: 111 dBm
• 72-channel multi--satellite GNSS
• Interfaces: NMEA 2000 - NMEA 0183 - USB-C
• Low power consumption: 110 mA - peak 1 A at 12 V

BOX CONTENTS:

• 1 - AMEC B650 Transponder AIS
• 1 - PA GPS Antenna-03
• 1 - AMEC B650 Power and Data Cable1 03 GPS PA Antenna
• 1 - USB cable
• 1 - PDF documentation
